Timex Metals is known as one of the biggest Stud Manufacturer, Supplier and Exporter in India. Two of the most commonly used SS Stud Bolts Materials by Stainless Steel Stud Bolt Manufacturers In India include the austenitic stainless steel grade 304 & 316.Both these two grades of SS Stud Bolts have good mechanical properties due to the high content of chromium, molybdenum and nickel in their alloy. These three elements from the primary alloying content in the Stainless Steel Stud Bolts.
Our company is one of the largest Manufacturers & Suppliers of Studs in IndiaStainless Steel 304 Stud Bolts have a corrosion resistance similar to that of 316 grade stainless steel. Chromium in both 304 and 316 SS Stud Bolts alloys provides oxidation corrosion resistance by forming a passivated oxide layer that self-heals in the presence of moisture and oxygen in the atmosphere. The term will be changed to 304L for low carbon content stainless steel and 316H for high carbon content stainless steel as the content increases. We are Largest Manufacturter Supplier of Rivets in India
Stud | Specification |
Grades | ASTM A193 B8,ASTM A193 GR.B8M |
Stainless Steel Stud Bolts Size | M2 - M100 |
Stainless Steel Stud Bolts Length | 6mm-500mm |
Standard | ISO 4017, DIN931, GB5783, DIN, ASTM, ANSI, JIS, EN, AS |
Length | upto 5 meters |
Stud Chemical Composition Table, Stud Chemical Chart, Chemical Chart of Stud, Steel Stud Chemical Composition Chart
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
SS 316 Studs | Min | - | - | - | 0 | - | 16.0 | 2.00 | 10.0 | - |
Max | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
SS 316L Studs | Min | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
SS 316H Studs | Min | 0.04 | 0.04 | 0 | - | - | 16.0 | 2.00 | 10.0 | - |
max | 0.10 | 0.10 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | - |
Grade | Tensile Str (MPa) min |
Yield Str 0.2% Proof (MPa) min |
Elong (% in 50mm) min |
Hardness | |
Rockwell B (HR B) max | Brinell (HB) max | ||||
SS 316 Studs | 515 | 205 | 40 | 95 | 217 |
SS 316L Studs | 485 | 170 | 40 | 95 | 217 |
SS 316H Studs | 515 | 205 | 40 | 95 | 217 |
Stud weight, Stud weight chart, weight chart for Stud, weight chart of Stud, Stud manufacturers weight chart, Stud weight chart table
NOMINAL SIZE (D) | BODY DIAMETER | HEAD THICKNEASTM A193 | ACROASTM A193 THE FLATS | ACROASTM A193 CORNERS | ||||
---|---|---|---|---|---|---|---|---|
D (MAX) | D (MIN) | H (MAX) | H (MIN) | F (MAX) | F (MIN) | C (MAX) | C (MIN) | |
m10 | 10.00 | 9.78 | 6.63 | 6.17 | 17.00 | 15.73 | 18.48 | 17.77 |
m12 | 12.00 | 11.73 | 7.76 | 4.24 | 19.00 | 17.73 | 20.78 | 20.03 |
m14 | 14.00 | 13.73 | 9.09 | 8.51 | 22.00 | 20.67 | 24.25 | 23.35 |
m16 | 16.00 | 15.73 | 10.32 | 9.68 | 24.00 | 23.67 | 27.71 | 26.75 |
m20 | 20.00 | 19.67 | 12.88 | 12.12 | 30.00 | 29.16 | 34.64 | 32.95 |
m24 | 24.00 | 23.67 | 15.44 | 14.56 | 36.00 | 35.00 | 41.57 | 39.55 |
m30 | 30.00 | 29.67 | 19.48 | 17.92 | 46.00 | 45.00 | 53.12 | 50.85 |
m36 | 36.00 | 35.61 | 23.38 | 21.63 | 55.00 | 53.80 | 63.51 | 60.79 |
m42 | 42.00 | 41.38 | 26.97 | 25.03 | 65.00 | 62.90 | 75.06 | 71.71 |
m48 | 48.00 | 47.38 | 31.07 | 28.93 | 75.00 | 72.60 | 86.60 | 82.76 |
m56 | 56.00 | 55.26 | 36.2 | 33.80 | 85.00 | 82.20 | 98.15 | 93.71 |
m64 | 64.00 | 63.26 | 41.32 | 38.68 | 95.00 | 91.80 | 109.70 | 104.65 |
m72 | 72.00 | 71.26 | 46.45 | 43.55 | 105.00 | 101.40 | 121.24 | 115.60 |
m80 | 80.00 | 79.26 | 51.58 | 48.42 | 115.00 | 111.00 | 132.72 | 126.54 |
m90 | 90.00 | 89.13 | 57.74 | 54.26 | 130.00 | 125.50 | 150.11 | 143.07 |
m100 | 90.00 | 99.13 | 63.9 | 60.10 | 145.00 | 140.00 | 167.43 | 159.60 |
Timex Metals manufactures Stud with precision and latest equipments. New technologically advanced manufactuStud equipments helps Timex Metals in processing and manufactuStud the best quality of Stud. With the help of newly found technologically advance equipment we are able to process Stud and supply containers of Stud Fasteners every month to different clients around the globe.
Fasteners are used in various industries worldwide. Timex Metals is known internationally for our quality of Fasteners that are used in different industries and applications.
Our Fasteners are impeccable in quality and that is why are loved widely by our large clientele. Fasteners produced by Timex Metals are used in various different projects worldwide. We have clients with regular demand for Fasteners in 6 different countries and we export Fasteners to additional 50+ Countries. Send us your inquiries via email – info@timexmetals.com or whatsapp us your requirements.
