Timex Metals is known as one of the biggest Monel Round Bars Manufacturers, Suppliers, Exporters, & Stockists in India. We offer one of the finest quality Monel Round Bars to different round bar drawing factories around the globe. Our aptitude in heat treatment gives us a preferred position in producing & exporting round bar with a nearby and specified chemistry and in accomplishing the required mechanical properties. Our round bar range from 5 mm To 500 mm and are provided in different conditions like Hot Rolled Round Bars, Annealed Round Bars and Pickled Round Bars.
Our company is one of the largest Manufacturers & Suppliers of Monel Round Bars in India. We produce and manufacture one of the top quality Monel Round Bars in different sizes and grades at our one of its kind manufacturing facility. Timex Metals is a well-known name around the globe and our quality Round Bars are in huge demand internationally. We are acheiving new heights with the help of our inhouse capabilities to produce one of the best quality Monel Round Bars.
Specifications | ASTM B166 / ASTM SB166 |
Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
Size |
5 mm To 500 mm |
Diameter | 0.1 mm to 100 mm |
Length | 100 mm To 3000 mm Long & Above |
Finish | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
Form | Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc. |
Monel Round Bars Chemical Composition Table, Monel round bar Chemical composition, Monel Round Bars Chemical Chart, Monel Round Bars Chemical Composition Chart
Grade | C | Mn | Si | S | Cu | Fe | Ni |
Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Monel Round Bars weight, monel Round Bar weight chart, weight chart for monel round bar, weight chart for monel round bar, monel round bar manufacturers weight chart, inconel round bar weight chart table
Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) |
---|---|---|---|---|---|
7 x 7 | 0.337 | 19 x 19 | 2.479 | 38 x 38 | 9.916 |
8 x 8 | 0.44 | 20 x 20 | 2.747 | 40 x 40 | 10.988 |
9 x 9 | 0.556 | 21 x 21 | 3.029 | 42 x 42 | 12.114 |
10 x 10 | 0.687 | 22 x 22 | 3.324 | 45 x 45 | 13.906 |
11 x 11 | 0.831 | 24 x 24 | 3.956 | 48 x 48 | 15.822 |
12 x 12 | 0.989 | 25 x 25 | 4.292 | 50 x 50 | 17.168 |
13 x 13 | 1.161 | 26 x 26 | 4.642 | 53 x 53 | 19.29 |
14 x 14 | 1.346 | 28 x 28 | 5.384 | 55 x 55 | 20.774 |
15 x 15 | 1.545 | 30 x 30 | 6.181 | 60 x 60 | 24.723 |
16 x 16 | 1.758 | 32 x 32 | 7.032 | 65 x 65 | 29.015 |
17 x 17 | 1.985 | 34 x 34 | 7.939 | 70 x 70 | 33.65 |
18 x 18 | 2.225 | 36 x 36 | 8.9 | 75 x 75 | 38.629 |
STANDARD | WERKSTOFF NR. | EN | UNS | AFNOR | BS | JIS | GOST |
Monel 400 | 2.4360 | NiCu30Fe | N04400 | NU-30M | NA 13 | NW 4400 | МНЖМц 28-2,5-1,5 |
Monel K500 | 2.4375 | - | N05500 | - | - | - | - |
Timex Metals manufactures inconel round bar with precision and latest equipments. New technologically advanced manufacturing equipments helps Timex Metals in processing and manufacturing the best quality of Monel Round Bars. With the help of newly found technologically advance equipment we are able to process Monel Round Bars and supply containers of Monel Round Bars every month to different clients around the globe.
Monel Round Bars are used in various industries worldwide. Timex Metals is known internationally for our quality of Monel Round Bars that are used in different industries and applications.
Our Monel Round Bars are impeccable in quality and that is why are loved widely by our large clientele. Monel Round Bars produced by Timex Metals are used in various different projects worldwide. We have clients with regular demand for Monel Round Bars in 6 different countries and we export Monel Round Bars to additional 50+ Countries. Send us your inquiries via email – info@timexmetals.com or whatsapp us your requirements.
Monel Round Bars Supply in Oil Plant | Rajasthan |
All types of monel round bar supply | Gujarat |
Monel Round Bars | Pune, Maharashtra |
Monel 400 Round Bars Supply | Vijaywada, Hyderabad |
Timex Metals is one of the only few largest Monel Round Bars suppliers in India. We have our sales offices is many different cities of India. We are leading suppliers in top industrial cities and locations that include GIDC in Gujarat state, MIDC areas in Maharashtra state, Peenya Industrial area in Bangalore, New Delhi, Hyderabad and more.
Suppliers in India | |||||
Bangalore | Mumbai | Chennai | Hyderabad | Kolkata | Pune |
New Delhi | Ahmedabad | Jaipur | Surat | Salem | Gandhinagar |
Bhiwandi | Tiruppur | Sivakasi | Jamnagar | Thiruvananthapura | Rajahmundry |
Bhubaneswar | Vijaywada | Firozabad | Bokaro Steel City | Rajkot | Bharuch |
Panna | Raipur | Cochin | Ludhiana | Panipat | Durgapur |
Peenya | Pimpri-Chinchwad | Channapatna | Kharagpur | Nashik | Bareilly |
Varanasi | Haldia | Rourkela | Bengaluru | Moradabad | Indore |
Visakhapatnam | Trivandrum | Pithampur | Dibrugarh | Angul | Gwalior |
Coimbatore | Kannur | Nagpur | Vadodara | Rudrapur | Noida |
Agra | Bhagalpur | Jamshedpur | Bhilai | Lucknow | kanpur |
Thane | Bhopal | Sri City | Bareilly | Hosdurg | Pithampur |
Yearly more than 40 tons of Monel Round Bars are exported from India, out of which Timex Metals exports 30% of the Monel Round Bars. We have a huge client base in Germany, UAE, Italy, France, United Kingdom, Canada, United States, Australia, Netherlands, Mexico, Saudi Arabia, Iran, Oman. We are regularly exporting Monel Round Bars to more countries and connecting with new clients in different parts of the world.
Exporting To Below Mentioned Countries | ||||
Saudi Arabia | Oman | Kuwait | Netherlands | Iran |
Bahrain | Qatar | UAE | Africa | China |
Nigeria | Mexico | Canada | Venezuela | United Kingdom |
United States | South Africa | Malaysia | Bangladesh | Turkey |
Singapore | Sri Lanka | Australia | Brazil | Germany |
France | Italy | South Korea | Poland | Belgium |
